Vertical lathe

Lathe: The product is described as follows:I. Main specifications: 1.1 Table diameter 2250 mm 1.2 Turning dia 2500 mm 1.3 Max.height of workpiece 1600 mm 1.4 Max.weight of workpiece 10 t 1.5 Height of tool bar section 40 mm 1.6 Max cutting force of right rail head 30 KN 1.7 left 30KN 1.8 Total cutting force 63 KN 1.9 Max torque of table 63 KN.m 1.10 Steps of table speeds 16 steps 1.11 Range of speeds of table 2-63r/min 1.12 Steps of feed rate of tool head 18 steps 1.13 Range of feed rate of tool head 0.25-90/min 1.14 Travel of ram for left & right rail head 1400 mm 1.15 Swivel limit of left & right rail head ±30° 1.16 Rapid travel speed 1560 mm/min 1.17 Max. travel of cross rail 1250 mm 1.18 Elevating speed of cross rail 350 mm/min 1.19 Machining accuracy IT6-IT7 1.20 Roughness of machining surface Ra1.6 1.21 Power of main power 55 kW 1.22 Power of elevating motor of cross rail 7.5 KW 1.23 Power of rapid speeds of tool head 2.2 KW 1.24 Total power of motor 70.6 KW 1.25 Weight of machine(appr) 33 t 1.26 Overall dimensions of machine 504x440x435 cm
